StartRichTextEditor

Rich text editor for Godot

using TextLine to draw text and Control to draw other(such as Image, Button, even a scene!!)

However, there are still many bugs (not recommended for use in serious projects), so it’s better to learn from it, and then fix or extend it.

No finished:

• delete selection
• good copy&paste
• perfect caret move
• enough config
• undo&redo
• scroll(follow caret)
• easy plugin system
• easy interface
• clean code

Finished:

• set&move caret
• make selection
• simple copy&paste
• ime input support
• parse text
• simple inspector

Usage

Start

• Add Node RichTextEditor (Dont't add other node to this node!!!) to your tree and run

• there is a example scene you can run:

  res://addons/start_rich_text_editor/example/MultiLineEditor.tscn

• Add Node RichTextEditorand extend the script

Basic

lines->line->{text,control}

control is a rect to place Control Node

Add init text

Use Array[Dictionary], if you want to add pure text, you can parse text to Array[Dictionary]

the dict is:

Text Block:

{
    "text":String
    "font_color":Color
    "bg_color":Color
    "font_size":int
}

Control Block:

{
    "key":String
    "size":Vector2
    "c":Control
}

A code example is in res://addons/start_rich_text_editor/example/rich_text_editor_1.gd(it is very useful~)

Add Control

You can use add_control or set 'c' in dict, and then add_child

To make [create and attach control] easier, you can make Factory to create control and set their prop, like that:

{key='btn1',size=Vector2(64,64),
type='button',
prop={
	text='button',
	color='#c0d470',
	bdc='#67835c',
	fc='#000000'
}}

class ControlFactory:
	static var table={
		button=ButtonFactory,
		image=ImageFactory
		}
	static func create(type:String,props:Dictionary)->Control:
		return table[type].create(props)

	class ButtonFactory:
		static func create(props:Dictionary):
			var btn=Button.new()
			btn.text=props.get('text','')
			if props.has('color'):
				var stylebox=StyleBoxFlat.new()
				stylebox.bg_color=Color.from_string(props.color,Color.NAVAJO_WHITE)
				stylebox.set_corner_radius_all(12)
				stylebox.set_border_width_all(1)
				stylebox.border_color=Color.from_string(props.get('bdc',''),Color.NAVAJO_WHITE)
				btn.add_theme_color_override('font_color',Color.from_string(props.get('fc',''),Color.NAVAJO_WHITE))
				btn.add_theme_stylebox_override('normal',stylebox)
			return btn

Add parser

Each time when text change, a signal will be emitted to call parse

You can use Callable(line:PowerLineEdit) to set default_parser in MultilineEditor.

Application

• command line
• code edit
• chat box
• doc

中文

用于Godot4的富文本编辑器

用TextLine渲染文字和Control进行渲染控件（之后在控件里塞什么都行，图片，场景）

现在很多bugs，属于demo一类的完成度，所以最好从中学习和修改
